Professional Diesel Concrete Pump 1400mm Feeding Height 500L Hopper Volume
Product introduction HBT100SR18186C
ZOOMWOLF concrete pumpHBT100SR18186C
This is a high output pressure(18MPa) concrete pump,powered by diesel engine.
Technical performance:
Output capacity(m3/h):57(high pres.)/103(low pres.)
Output pressure(MPa):18(high pres.)/10(low pres.)
Distribution Valve:S valve
Rated power of BF6M1013 diesel engine(kW):186
Oil pres.of the pumping system(MPa):32
Hydraulic system circle form:Twin-pump and -circuit open system.
Oil tank volume(L):500
Overall dimension L×W×H(mm):6460×1962×2620
Total mass(kg):6685
About the easy to wear parts of concrete pump
Concrete pump is through the pressure delivery of concrete, some parts and components directly with concrete or slurry leakage particles contact and friction or corrosion and inevitable damage. The extent of their damage depends on many factors, such as the material of the parts themselves, the stiffness of the concrete aggregates, pumping pressure and pumping speed.
In the composition of the concrete pump, the following parts are easy to wear, should be an appropriate amount of spare parts inventory to meet the needs of timely replacement: eye-glass plate, cutting ring, S tube, transition sleeve, mixing shaft, mixing blade, shaft end seals, conveying pipe, hose, rubber ring, rubber spring, concrete piston, etc..
18-fig.(1)Examples of the easy to wear parts
