Professional Concrete Pump Easy Operation HBT100SR18186C
Product introduction HBT100SR18186C
ZOOMWOLF concrete pumpHBT100SR18186C
This is a high output pressure(18MPa) concrete pump,powered by diesel engine.
Technical performance:
Output capacity(m3/h):57(high pres.)/103(low pres.)
Output pressure(MPa):18(high pres.)/10(low pres.)
Distribution Valve:S valve
Rated power of BF6M1013 diesel engine(kW):186
Oil pres.of the pumping system(MPa):32
Hydraulic system circle form:Twin-pump and -circuit open system.
Oil tank volume(L):500
Overall dimension L×W×H(mm):6460×1962×2620
Total mass(kg):6685
Materials and specifications are subject to change without notice.
Deutz(made in CHINA)diesel engine possesses blowing cooling to greatly reduce the temperature of the hydraulic system.
Electric control system
(1) Control boxcenclosed.Touch screen:allkinds of operating parameters can be stored and displayed.
(2) Double controller auto-pumping technology.
Hydraulic system
(1) Circuit:twin-pump,twin-circuit open system.
(2) Controllable air coolingfull flow forced air-cooling radiator,ensure the hydraulic system works under the best temperature condition(60℃).
(3) Oil pumps&main valves:from REXROTH:manual reliefvalve is made in Italian GALTECH.Automatic lubrication adopts multi-point centralized phase sequence follow-up design, which is precise, concise, fuel-efficient and reliable.
Concrete pump requirements for concrete
It should be clear that not all concrete is "pumpable".
Concrete pump can pump concrete basic premise is that the concrete has good workability, can pump. Usually measured by the slump of concrete:slump of 180mm or so is best for pumping.
Pumping slump of ordinary strength concrete (such as C30,fcu= 30MPa) must be greater than 10mm, while pumping slump of high strength concrete (such as C60,fcu=60MPa) must be ≥ 180mm.
4-fig.(1) slump of concrete
